Scythe, most people will know them. In case you don’t, Scythe have been around for years and they have a notable reputation in cooling, that means sites like Hardwareslave, will always take note of their products. We have a couple of coolers coming in the next couple of weeks and we start with the Scythe Ninja 4. We recently reviewed the Scythe Grand Kama Cross 3 and last year we tested the Scythe Mugen MAX. Both scored well and we were happy to see Scythe still around after all these years. The Ninja 4 is the latest Ninja evolve from the Scythe design office. If you look at the website, there are around eight Ninjas and there are probably more coming! So what does this latest version offer?
It features a new T-M.A.P.S technology, an optimized alignment of heat pipes and a back-plate based on Scythe’s Hyper Precision Mounting System (H.P.M.S) for easy installation. It’s also an evolution of the M.A.P.S technology with the “T” meaning three dimension. It also comes with an interesting fan, the Glide Stream 120mm PWM Fan. The fan has an embedded three-point switch for fan speeds, allowing the user to choose between extremely silent operation or maximum cooling power.
It also continues the flexible fan mounting, and although this is not unique, the Ninja 4 offers a fan mounting point on all four sides of the heatsink. Scythe also implement the HPMS (Hyper Precision Mounting System) mounting system in a hope to aid an easier installation process.
|Socket compatibility||Intel Socket LGA775, LGA1150, LGA1151, LGA1155, LGA1156, LGA1366, LGA2011 / 2011-v3 (Square ILM)|
AMD Socket AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+
|Dimension ( with fan )||(L) 130mm x (W) 153mm x (H) 155mm (with fan)|
|Weight ( with fan )||900 g|
|Baseplate Material||Nickel-plated Copper|
|Heat pipes||6x 6 mm|
|Fan||GlideStream 120 PWM|
|Fan Dimension||120 x 120 x 25mm|
|Fan Rated Speed||L: 300 upm (±300) ~ 800 upm (±10%|
M: 300 upm (±300) ~ 1150 upm (±10%)
H: 300 upm (±300) ~ 1500 upm (±10%
|Fan Noise Level||L: 4,0 ~ 12,5 dBA |
M: 4,0 ~ 23,5 dBA
H: 4,0 ~ 29,5 dBA
|Fan Air Flow||L: 21,97 ~ 73,90 m³/h | 12.93 ~ 43.50 CFM|
M: 21,97 ~ 112,96 m³/h | 12.93 ~ 63.73 CFM
H: 21,97 ~ 143,78 m³/h | 12.93 ~ 84.64 CFM
|Fan Air Pressure||L: 0,69 ~ 4,90 Pa / 0,07 ~ 0.50 mmH²O|
M: 0,69 ~ 10,40 Pa / 0,07 ~ 1.06 mmH²O
H: 0,69 ~ 17,55 Pa / 0,07 ~ 1.79 mmH²O
The Scythe Ninja 4 is a traditionally tall cooler with one 120mm fan included. You can fit one or two or some of your own if you want. We could even speculate that a heatsink of this size could almost be used passively, though test at your own risk.
